AS-ONU50 model ONU is a user terminal device independently developed in line with such industrial background.The
device has built-in two-layer switching function and three-layer routing function. With compact structure and small
appearance, it is a kind of FTTH optical network unit with high performance and low power consumption, which is
very suitable for the application requirements of various data services in FTTH networking scenarios of various oper
ators.AS-ONU50 is an XPON product that can be adapted to EPON and GPON networks without replacing
equipment and firmware.
♦ Support EPON/GPON mode and switch mode automatically
♦ GPON:Compliance with IEEE 802.3ah & itu-t g.984.x standard
♦ GPON:8 T-CONTs,32 GEM Ports
♦ Integrate OMCI(GPON)/OAM(EPON) and TR-069 remote configuration and maintenance
♦ Layer 3 Home Gateway/CPE features with Hardware NAT, support Multiple WAN, Route/Bridge mode, etc
♦ Layer 2 Switching, support 802.1Q VLAN, 802.1P QOS, Bandwidth Control, Spanning Tree, etc
♦ Bi-directional FEC
♦ Support firewall level Settings, support based on URL/MAC/ IP/ address frame filtering
♦ Support multicast IGMP v2 proxy/ snooping, support MLD proxy/ snooping
♦ Qos supports PQ, WRR, and CAR queue scheduling
♦ Provide Maximum rate 1775Mbps Wireless interface, 2T2R external antenna, support multiple
♦ SSID Settings
♦ Support DDSN, ALG, DMZ and UPNP
♦ Support CATV interface for Video Service,support to turn off CATV functionality
♦ Dual band Wi-Fi, Superior performance of Wireless 11n and 11ac Transmission
♦ Compatible with 95% Third-party OLTs (Including Huawei/ZTE/Fiberhome/AS-PON and so on)
